Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
Issue
11.01.D
109
11.11.2 Copy Options
When you copy a distant playlist from the VGA, or a local/distant playlist from the Remote
Panel to the local EVS server, you have different options:
EDL only or EDL+Clips Copy
• The EDL copy copies only the playlist definition and the playlist elements themselves
remain at the original location.
• The EDL+Clips copy copies the playlist definition and the playlist elements to the
server on which the copy is requested.
Long or Short Copy
When you copy the material of the playlist elements, you can perform a long or short
copy:
• The short copy copies the material between the IN and OUT points of the playlist
elements, with clip guardbands as defined on the destination system.
• The long copy copies the original clips, not only the material defined as the playlist
element. This makes a difference when the playlist element has been trimmed
compared to the original clip.
11.11.3 Possible Copy Actions
The following table provides an overview on the possible actions on the Remote Panel
and on the VGA:
VGA Remote Panel
Local PL
to local
position
Distant
PL to
local
position
Distant
PL to
distant
position
Local PL
to local or
distant
position
Distant
PL to
local
position
Distant
PL to
distant
position
Copy (EDL) Yes Yes No Yes Yes Yes
Copy
(EDL+Short
Clip copy)
No Yes No Yes Yes Yes
Copy
(EDL+Long
Clip copy)
No Yes No Yes Yes Yes
