Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
160
Displayed Letter Function
E Erases unwanted portion of graphic. See also Section 14.3.
k / >k< Keyer off / on. See also Section 14.3.
L Calls the Library module where drawing, logos, … can be
saved.
C Marks CUE OUT point on current clip.
S Plays back the clip at slow motion speed. The speed of slow
motion is predefined in the PGM Speed/Var max parameter in
the Operational Setup menu (p.9.1 F3).
P Plays back the current clip at normal speed
The clip countdown displays the field time. This means that the countdown matches the
slow motion speed.
Note
Selecting
C (clear) from the monitor enters the Clear menu and the DFC menu.
DFC menu allows you to select the brush color from a YUV color palette
If working in network mode, Painting can be performed on remote clips as well as on local
clips.
14.3 Function Description
Straight Line / Broken Line Drawing (L)
Select L on the Paint Mode monitor display. You will then be prompted to enter the first
point of the line.
Place the pen at the start point and press lightly. Then place the pen at the next point and
press lightly again. A straight line appears to connect these 2 points. Repeat this as many
times as necessary until the line is complete, then place the pen over the “ESC” area in
the top right corner of the OSD and press lightly. The system automatically defaults back
to Freehand Drawing mode.
Circle Drawing (O)
Select this menu to draw circles.
A menu allows you to choose between the following options:
• Set centre (default): A pointer appears on the screen to let you choose the centre of
the circle. The radius will be the one last used or the default one if none has been
defined before.
