EVS XT3 MulticamLSM Version 11.01 - November 2012 Operation Manual - Manual (Page 112)

Issue
11.01.D
Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
102
FX Dur
The FX Dur function (C key) sets the duration of the transition effect. The default value
that initially appears is determined by the value set in the Setup menu. The effect
duration will affect the transition at the beginning of the selected clip. Use the lever to
adjust the value, then press ENTER to confirm.
Effect
The Effect function (SHIFT+C key) is used to select the type of transition effect
(Mix/Wipe/Cut/Fade). Move the lever to set the type of effect, when Effect is highlighted.
Press ENTER to validate.
For more information on the effects types, refer to the section 11.15 ‘Transition Effects’,
on page 118.
Delete
The Delete function allows the operator to quickly edit a playlist by removing the selected
clip. The clip that has been «cut» can then be inserted into another location. This clip is
displayed on the second PRV output. To insert it at another position in the playlist, simply
go to that position using the jog dial and press the Insert key (or TAKE).
11.9.2 Secondary Menu in Playlist Edit Mode
Introduction
You can access the secondary menu of the Playlist Edit mode pressing MENU on the
Remote Panel when you are in the main menu of the Playlist Edit mode.
Clr Unav.
OtherAng Add cut
Replace MakeLoc Redo Undo
Replace
The Replace function makes it possible to replace a portion of a playlist by the same A/V
material to which effects have been added (externally or internally). This consolidates the
effects within the playlist. For more information, refer to the section 11.18 ‘Replace
Function’, on page 137.
Clr Unav.
The Clr Unav. (Clear Unavailable) function (SHIFT+A key) allows the user to remove the
clips that are not available on the network from all local playlists. This function is only
visible when unavailable clips are present and when the Split Audio Editing is turned off.
