11.18.3 Replace Edit and Replace Playback
Modes
Similar to the playlist, the Replace function has two modes:
The Replace Edit Mode
This mode allows to specify the following information for the Replace:
• IN point and OUT point, for the section to replace in the playlist. The OUT point can
also be defined during the Replace itself.
• Loop mode parameters. See also the section ‘Loop Mode in the Replace Function’,
on page 140.
In the Replace Edit mode, the playlist is considered as one entity on which you can mark
one IN point and one OUT point (pressing the IN and OUT points does not retrim the
current playlist clip).
Those IN and OUT points will be used to determine what portion of the playlist will be
replaced.
The Replace Playback Mode
In this mode, you play the playlist back and insert the new section between the defined IN
and OUT points.
After you have selected the required settings for the Replace function, the Replace
Playback mode is automatically activated: the playlist is cued before the IN point (to
create guardbands), ready to be initiated.
The playlist is played at the speed defined in the playlist but the lever can also be used to
vary the playback speed.
When the Protect OUT point of the clip is reached, a clip containing the IN and OUT
points with the guardbands is created on the Receive page defined in the Setup menu.
The loop is stopped and the user switches back to match Frame Edit mode.
11.18.4 Replace with IN/OUT Points or with IN
Point Only
You can perform a Replace action in two ways:
• by defining an IN and OUT points in the Replace Edit mode.
• by defining only an IN point in the Replace Edit mode, and defining the OUT point
while you perform the Replace in the Replace Playback mode.
For more information on how to perform a Replace, refer to the section ‘How to Perform a
Replace’, on page 139.
