Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
168
In the Static Zoom mode, at the bottom left of the screen, a “P” appears on the OSD to
define the position of the static zoom.
Just click on the
P and move the cursor to indicate where the static zoom should be.
Keyframe Information Display
On the OSD, a second line is added to indicate the number of keyframes marked and the
position of the current keyframe.
The information displayed can be interpreted as follows:
Display Meaning
---/--- No keyframes are defined.
---/021 21 keyframes are defined but the user is not on a keyframe.
012/021 21 keyframes are defined and the user is on keyframe 12 of
21.
Transparency Options
Select the last choice in the transparency options to set the background in black and
white.
