Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
Issue
11.01.D
7
6.
Operational Block 2
PLAY
Initiates playback
NETWORK
Enters the XNet menu. (connects to other servers on
the network)
LAST CUE
Re-cues EVS server to previous cue point
GOTO TC
Allows timecode entry, with «F» keys
FAST JOG
Used with jog dial for rapid, manual re-cue. This mode
is automatically reset after PLAY/LIVE commands.
MARK
Used to enter re-usable cue points (256 cycling cues).
RECORD
Initiates “E2E” mode
RETURN
Inside a clip, allows the operator to return to the same
picture inside the record train, if it still exists.
PRV CTL
Enables/disables the Preview Control mode.
PAGE
Selects current clip page, from 1 to 10.
7.
LCD Display
Provides current status of system
2.2 Led Colours
A selected key lights red.
When a key lights green, it means a value in relation with this key exists.
For example:
F1 to F0 keys
•
Green light means a clip has been stored in relation with the key.
•
Green flashing light means a clip is being created.
•
Red light means the clip associated to the key is playing or is ready to play.
•
Red flashing light means a clip is being deleted (in network mode).
