Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
Issue
11.01.D
139
Important
The IN and OUT points cannot be marked on a transition (including split audio
transitions and swap zones) or on a split zone (the key will flash red when it is
the case).
11.18.5 How to Perform a Replace
You first define the Replace function in the Replace Edit mode. Then, you execute the
Replace function in the Replace Playback mode.
To perform a Replace, proceed as follows:
1. Open the playlist in which you want to replace a section in Playlist Edit mode.
2. In Playlist Edit mode, press
Menu on the Remote Panel to access the secondary
menu.
3. Press the A key to enter the Replace Edit mode.
4. Use the jog dial to reach the desired IN point for the Replace section and press the IN
key to mark it.
When the IN point has been marked, the display switches to:
The Int. Loop (B) and Ext. Loop (C) keys are blinking.
5. If you want to specify the OUT point for the Replace section at this stage, jog to the
requested point and press the OUT key. Otherwise, you can define the OUT point
while you perform the Replace.
6. Press the B or C key to select whether you will use the internal loop or external loop
to perform the Replace.
For more information on the loop type and additional parameters, refer to the section
‘Loop Mode in the Replace Function’, on page 140.
The playlist is cued before the IN point (to create guardbands), ready to be initiated.
A message appears on Remote: “ Start Replace: lever or play button”.
7. Push the lever or press the Play key on the Remote Panel to shift to the Replace
Playback mode and start the Replace process.
8. If you have not defined the OUT point for the Replace in step 5, press the OUT key
when you reach the desired OUT point.
While the Replace is being performed, the following messages are displayed on the
OSD:
“Replace in Progress”
“Clipping guardbands”
“Replace by clip xxx”
On the Remote Panel, a confirmation message pops up:
9. Press Enter on the Remote Panel to validate the Replace:
The material between the IN and OUT points is replaced with the newly created clip.
The playlist returns to Playlist Edit mode, positioned at the end of the inserted clip.
You can also cancel the Replace by pressing the Menu key on the Remote Panel.
Cam A +2fields
Replace Int.Loop Ext.Loop
Replace in/out by clip xxx ?
MENU: Cancel – ENTER: OK.
