14. Paint Mode
14.1 Introduction
Note
The Paint mode is a software option, which requires the license code 114 being
installed. For more information on the required license key, contact the Support
or Sales teams.
The Paint mode is not available on EVS servers working with 10-bit codecs.
The functionality of this software package can be operated using the tablet and the stylus,
or a touch screen. The normal pointing device is the tablet. It is selected in the Setup
menu.
Change the
Pointing device parameter in the Operational Setup menu (p.9.2 F2) to
toggle between the tablet and the touch screen (only when the touch screen is available).
The touch screen must always be connected to the RS422 port #6 and defined with the
RS422 #6 parameter in the Operational Setup menu (p.T2.2 F6).
The use of the Loop function allows the operator to record the effect back into the 1
st
record channel of the server, and to create a clip with the paint feature. Rolling a clip
while in the Loop mode, in Painting, and dissolving paint image on/off allow for a very
powerful feature.
