18.5.2 NAC Camera Hi-Motion II
Application Start
At application start, this camera is in ARM mode and the recording starts on the first
memory block.
Configuration Parameter Values
• Port = RS422
• Protocol = Sony 9-PIN
• The PGMSpeed parameter value 1000 is available.
• Last Cue values (when Cues is Off): 50, 100, 200, 300, 400, 600, 1200, 1600
Key Behavior
• PLAY: this key initiates a replay on the current memory block. The replay position
can be set on the camera (beginning, end, specific position in the block).
• TAKE: this key is operational in ARM mode. In loop mode, once the last block is
used, the recording starts again on the first block.
• RECORD: the remote beeps if the CAM key refers to an empty block.
• RECORD: pressing this key while the current block is recording does not send any
command to the camera.
• ENTER: press this key together with a CAM key to lock the corresponding memory
block.
o If the corresponding block is empty, the remote beeps.
o You cannot lock a recording block.
• Last Cue: If no cue points have been defined, pressing this key will stop the
recording and go back to the first recorded frame of the current memory block.
• CAM keys:
o Selecting a block for the first time loads the block at the frame specified in the
camera menu. You can then brwse through it or play it.
o Selecting the same block another time loads it at the frame it was last loaded on.
Cue points management
• Cue points are only managed in Loop mode.
• When a new ARM/REC command is issued on a block, all its cue points are cleared.
• If the Last Cue command cannot access the desired TC-pre-roll, the player remains
on the current cue point.
