20 April 2005 M-Series User Manual 301
Mechanical specifications
Mechanical specifications
Electrical specifications
The following sections describe the electrical specifications:
Serial Digital Video (SDI)
Dimension Measurement
Height 7 in (177 mm)
Width 17.75 in (450 mm)
Depth
a
a.
Adjustable rack-mounting ears accommodate different rack depth limitations.
25.5 in (647 mm) Rack-mounting ears in forward position.
Weight: 55 lbs. (25 kg)
Parameter Specification
Video Standard 525 Line or 625 Line component
Number of Inputs 1 per record channel
Number of Outputs 2 per play channel
Data format Conforms to SMPTE 259M
Number of bits 10bits
Embedded Audio a
a.
Available only on models equipped with digital audio.
Data format conforms to SMPTE 272M-1994
48 KHz (locked to video) and 16-bit pcm only
User selectable audio group 1- 4
User can disable embedded audio on SDI output
Connector BNC, 75 ohm, No loop-through
Max Cable Length 225 meters (738 ft)
(Belden 8281 type cable)
Return Loss
≥15db, 5Mhz to 270Mhz
