Chapter 10 Using Remote Control Protocols
Guide to Protocol Player: Protocol Only mode
The Protocol control only mode allows you to only monitor play channel operations
and view clip information. All control comes from the external device. The buttons,
menu items, and other interface controls are disabled. You can select this mode by
choosing the
Protocol control only
option in the Options dialog box. (
the control port and control mode” on page 282
The following describes the indicators displayed Protocol control only mode.
Control
Description and User Operation
!
Assignable Buttons
Assignable buttons allow you to modify the button assignment to
best suit your workflow. Holding down a button longer than one
second opens the button pop-up menu which lists the alternative
button choices. Button choices include Options
or Properties. The
buttons function the same as the context menu items. See
later in this table.
"
Current Timecode
Indicates the current timecode of the timecode of the clip. The
timecode value of XX:XX:XX:XX is displayed when there is no
recorded timecode.
See “Striping timecode (replacing the timecode
Clip
Timecode
PB or EE
Mode
(Indicates the
selected mode)
Context
Menu
2
3
4
Clip Name &
Current Bin
6
Assignable
Buttons
(Default buttons
are shown)
1
Time Dome
8
Protocol
Monitor
Button
9
Thumbnail
(Current and
Preview clips)
7
5
Countdown
Timecode
