Chapter 4 Parameters|

Revision August 2008, 03VE, SW V2.04

4-29

In version 2.02, the parameters are from Pr.08-00 to Pr.08-15.

Pr.

Explanation

Settings

Factory

Setting

VF VFPG SVC FOCPG TQRPG

08-15

Filter Time for PID Feedback

0.1~300.0 sec

5.0


Group 10 Speed Feedback Control Parameters
In version 2.02, the parameters are from Pr.10-00 to Pr.10-28.

Pr.

Explanation

Settings

Factory

Setting

VF VFPG SVC FOCPG TQRPG

10-28 PG Mechanical Gear B1

1~5000

100


Group 11 Advanced Parameters
In version 2.02, the parameters are from Pr.11-00 to Pr.11-30.

Pr.

Explanation

Settings

Factory

Setting

VF VFPG SVC FOCPG TQRPG

11-09 Level of Phase-loss

0.0~320.0 60.0

11-10

Reserved

11-18

|

11-28

Reserved

11-29

Accumulative Operation Time of Phase-
loss

0~65535 (hour)

0

11-30 APR Curve Time

0.00~655.35 sec

3.00

Version 2.04
Group 0 System Parameters

Pr.

Explanation

Settings

Factory

Setting

VF VFPG SVC FOCPG TQRPG

00-03 Start-up Display Selection

0: Display the frequency command value (LED F)
1: Display the actual output frequency (LED H)
2: Multifunction display, see Pr.00-04 (LED U)
3: Display the output current (A)

0

00-04

Content of Multi Function
Display

0: Display output current (A)
1: Display counter value (C)
2: Display output frequency (H)
3: Display DC-BUS voltage (

u

)

4: Display output voltage (E)
5: Output power factor angle (n)
6: Display output power (kW)
7: Display actual motor speed (HU)
8: Display estimate output torque (kg-m)
9: Display PG position (G) (refer to Pr.10-00 and Pr.10-
01)
10: Display PID feedback
11: Display AVI (%)
12: Display ACI (%)
13: Display AUI (%)
14: Display the temperature of heat sink (°C)
15: Display the temperature of IGBT (°C)
16: The status of digital input (ON/OFF)
17: The status of digital output (ON/OFF)
18: Multi-step speed
19: The corresponding CPU pin status of digital input
20: The corresponding CPU pin status of digital output
21: Number of actual motor revolution (PG1 of PG
card)
22: Pulse input frequency (PG2 of PG card)
23: Pulse input position (PG2 of PG card)

0


Group 2 Digital Input/Output Parameters
