B.3 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A)
Bussmann P/N
VFD007V23A-2 5.7
5.0
10
JJN-10
VFD007V43A-2 3.2
2.7
5
JJN-6
VFD015V23A-2 7.6
7.0
15
JJN-15
VFD015V43A-2 4.3
4.2
10
JJN-10
VFD022V23A-2 15.5
11
30
JJN-30
VFD022V43A-2 5.9
5.5
15
JJN-15
VFD037V23A-2 20.6
17
40
JJN-40
VFD037V43A-2 11.2
8.5
20
JJN-20
VFD055V23A-2 26
25
50
JJN-50
VFD055V43A-2 14
13
30
JJN-30
VFD075V23A-2 34
33
60
JJN-60
VFD075V43A-2 19
18
40
JJN-40
VFD110V23A-2 50
49
100 JJN-100
VFD110V43A-2 25
24
50
JJN-50
VFD110V43B-2 25
24
50
JJN-50
VFD150V23A-2 60
65
125 JJN-125
VFD150V43A-2 32
32
60
JJN-60
VFD185V23A-2 75
75
150 JJN-150
VFD185V43A-2 39
38
75
JJN-70
VFD220V23A-2 90
90
175 JJN-175
VFD220V43A-2 49
45
100 JJN-100
VFD300V23A-2 110
120
225
JJN-225
VFD300V43A-2 60
60
125 JJN-125
VFD370V23A-2 142
145
250
JJN-250
VFD370V43A-2 63
73
150 JJN-150
VFD450V43A-2 90
91
175 JJN-175
VFD550V43C-2 130
110
250
JJN-250
VFD750V43C-2 160
150
300
JJN-300
