Chapter 4 Parameters|

4-52

Revision August 2008, 03VE, SW V2.04

Control

mode

VF

VFPG

SVC

Settings

230V series

0.1 to 255.0V

Factory Setting: 0.0

460V series

0.1 to 510.0V

Factory Setting: 0.0

01-41

4th Output Frequency Setting 2

Unit: 0.01

Control

mode

VF VFPG SVC

FOCPG TQRPG

Factory Setting: 0.00

Settings 0.00~600.00Hz

01-42

4th Output Voltage Setting 2

Unit: 0.1

Control

mode

VF

VFPG

SVC

Settings

230V series

0.1 to 255.0V

Factory Setting: 0.0

460V series

0.1 to 510.0V

Factory Setting: 0.0

V/f curve setting is usually set by the motor’s allowable loading characteristics. Pay special

attention to the motor’s heat dissipation, dynamic balance, and bearing lubricity, if the loading

characteristics exceed the loading limit of the motor.

For the V/f curve setting, it should be Pr.01-01

≥ Pr.01-03≥ Pr.01-05≥ Pr.01-07. There is no

limit for the voltage setting, but a high voltage at the low frequency may cause motor damage,

overheat, stall prevention or over-current protection. Therefore, please use the low voltage at

the low frequency to prevent motor damage.

Pr.01-35 to Pr.01-42 is the V/f curve for the motor 2. When multi-function input terminals Pr.02-

01 to Pr.02-14 is set to 14 and enabled or switch to the

Δ-connection, the AC motor drive will

act as the 2nd V/f curve.

01-09

Start Frequency

Unit: 0.01

Control

mode

VF VFPG SVC

FOCPG

Factory Setting: 0.50

Settings

0.00~600.00Hz

When start frequency is higher than the min. output frequency, drives’ output will be from start

frequency to the setting frequency. Please refer to the following diagram for details.

Fcmd=frequency

command,

Fstart=start frequency (Pr.01-09),

fstart=actual start frequency of drive,

Fmin=4th output frequency setting (Pr.01-07/Pr.01-41),

Flow=output frequency lower limit (Pr.01-11)
