Appendix A Specifications
Voltage Class
230V Class
Model Number VFD-XXXV
007
015
022
037
055
075 110
150
185
220
300
370
Max. Applicable Motor Output
(kW)
0.75
1.5
2.2
3.7
5.5
7.5 11 15
18.5
22
30
37
Max. Applicable Motor Output (hp) 1.0
2.0
3.0
5.0
7.5
10
15
20
25
30
40
50
Rated Output Capacity (kVA)
1.9
2.7
4.2
6.5
9.5
13 19 25
29
34
46
55
Rated Output Current for
Constant Torque (A)
5.0
7.5
11
17
25
33 49 65
75
90
120
146
Rated Output Current for
Variable Torque (A)
6.25
9.4
13
21
31
41 61 81
93
112
150
182
Maximum Output Voltage (V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.00~600.00 Hz
Outp
ut Rati
ng
Carrier Frequency (kHz)
15 9 6
Rated Input Current (A)
6.4
9.9
15
21 25
33
52
63
68
79
106
126
Rated Voltage/Frequency
3-phase
200-240V, 50/60Hz
Voltage Tolerance
±
10%(180~264 V)
Inpu
t Ratin
g
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method
Natural
Fan Cooled
Weight (kg)
2.7
3.2
4.5
6.8
8
10
13
13
13
13
36
36
Voltage Class
460V Class
Model Number VFD-XXXV
007 015 022 037 055 075 110 150 185 220 300 370 450 550 750
Max. Applicable Motor Output
(kW)
0.75 1.5 2.2 3.7 5.5 7.5
11 15 18.5 22
30
37
45
55
75
Max. Applicable Motor Output
(hp)
1.0 2.0 3.0 5.0 7.5
10
15 20 25
30
40
50
60
75 100
Rated Output Capacity (kVA) 2.3 3.2 4.2 6.3 9.9
14
18 24 29
34
46
56
69
80 100
Rated Output Current for
Constant Torque (A)
3.0 4.2 6.0 8.5
13
18
24 32 38
45
60
73
91 110 150
Rated Output Current for
Variable Torque (A)
3.8 5.3 7.5
10
16
22
30 40 47
56
75
91 113 138 188
Maximum Output Voltage (V)
3-phase Proportional to Input Voltage
Output Frequency (Hz)
0.00~600.00 Hz
Outp
ut Rati
ng
Carrier Frequency (kHz)
15
9
6
3-phase
380~480V
Rated Input Current (A)
4.0 5.8 7.4 9.9
12
17
25 27 35
42
56
67
87 101 122
Rated Voltage
3-phase 380 to 480 V
Voltage Tolerance
±
10%(342~528 V)
Inpu
t Ratin
g
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method
Natural
Fan Cooled
Weight (kg)
2.7 3.2 4.5 6.8
8
10
13 13 13
13
36
36
36
50
50
