Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-9
Group 3 Analog Input/Output Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
03-00
Analog Input 1 (AVI) 0: No function 1 ○ ○ ○ ○ ○
03-01
Analog Input 2 (ACI) 1: Frequency command (torque limit under TQR control
mode) 0 ○ ○ ○ ○ ○
03-02
Analog Input 3 (AUI) 2: torque command (torque limit under speed mode) 0 ○
3: Torque compensation command ○ ○ ○ ○ ○
4: PID target value (refer to group 8) ○ ○ ○ ○
5: PID feedback signal (refer to group 8) ○ ○ ○ ○
6: P.T.C. thermistor input value ○ ○ ○ ○ ○
7: Positive torque limit ○
8: Negative torque limit ○
9: Regenerative torque limit ○
10: Positive/negative torque limit ○
11: PID feedback signal of tension ○ ○ ○ ○ ○
12: Line speed ○ ○ ○ ○ ○
13: Reel diameter ○ ○ ○ ○ ○
14: PID target value of tension (tension closed-loop) ○ ○ ○ ○ ○
15: Tension setting (tension open-loop) ○
16: Zero-speed tension ○
17: Tension taper ○
03-03
Analog Input Bias 1
(AVI)
-100.0~100.0%
0 ○ ○ ○ ○ ○
03-04
Analog Input Bias 2
(ACI)
-100.0~100.0%
0 ○ ○ ○ ○ ○
03-05
Analog Input Bias 3
(AUI)
-100.0~100.0%
0 ○ ○ ○ ○ ○
03-06
Positive/negative Bias
Mode (AVI) 0 ○ ○ ○ ○ ○
03-07
Positive/negative Bias
Mode (ACI) 0 ○ ○ ○ ○ ○
03-08
Positive/negative Bias
Mode (AUI)
0: Zero bias
1: Lower than bias=bias
2: Greater than bias=bias
3: The absolute value of the bias voltage while serving
as the center
4: Serve bias as the center
0 ○ ○ ○ ○ ○
03-09
Analog Input Gain 1
(AVI)
-500.0~500.0%
100.0 ○ ○ ○ ○ ○
03-10
Analog Input Gain 2
(ACI )
-500.0~500.0%
100.0 ○ ○ ○ ○ ○
03-11
Analog Input Gain 3
(AUI)
-500.0~500.0%
100.0 ○ ○ ○ ○ ○
03-12
ACI/AVI2 Selection 0: ACI
1: AVI 2 0 ○ ○ ○ ○ ○
03-13
Analog Input Delay
Time (AVI)
0.00~2.00 sec
0.01 ○ ○ ○ ○ ○
03-14
Analog Input Delay
Time (ACI)
0.00~2.00 sec
0.01 ○ ○ ○ ○ ○
03-15
Analog Input Delay
Time (AUI)
0.00~2.00 sec
0.01 ○ ○ ○ ○ ○
03-16
Addition Function of
the Analog Input 0: Disable (AVI, ACI, AUI)
1: Enable ○ ○ ○ ○ ○
03-17
Loss of the ACI Signal 0: Disable
1: Continue operation at the last frequency
2: Decelerate to stop
3: Stop immediately and display E.F.
0 ○ ○ ○ ○ ○
0: Output frequency (Hz) 0 ○ ○ ○ ○ ○
03-18
Analog Output
Selection 1
1: Frequency command (Hz) ○ ○ ○ ○ ○
2: Motor speed (Hz) ○ ○ ○ ○ ○
03-21
Analog Output
Selection 2
3: Output current (rms) ○ ○ ○ ○ ○
4: Output voltage ○ ○ ○ ○ ○
03-24
Analog Output
Selection 3
5: DC Bus Voltage ○ ○ ○ ○ ○
6: Power factor ○ ○ ○ ○ ○
7: Power ○ ○ ○ ○ ○
8: Output torque ○ ○ ○ ○ ○
