Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-21
Group 9 Communication Parameters
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
09-00
Communication
Address 1~254 1 ○ ○ ○ ○ ○
09-01
COM1 Transmission
Speed 4.8~115.2Kbps 9.6 ○ ○ ○ ○ ○
09-02
COM1 Transmission
Fault Treatment 0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning and keep operation 3 ○ ○ ○ ○ ○
09-03
COM1 Time-out
Detection 0.0~100.0 sec 0.0 ○ ○ ○ ○ ○
09-04
COM1 Communication
Protocol 0: 7N1 (ASCII)
1: 7N2 (ASCII)
2: 7E1 (ASCII)
3: 7O1 (ASCII)
4: 7E2 (ASCII)
5: 7O2 (ASCII)
6: 8N1 (ASCII)
7: 8N2 (ASCII)
8: 8E1 (ASCII)
9: 8O1 (ASCII)
10: 8E2 (ASCII)
11: 8O2 (ASCII)
12: 8N1 (RTU)
13: 8N2 (RTU)
14: 8E1 (RTU)
15: 8O1 (RTU)
16: 8E2 (RTU)
17: 8O2 (RTU) 1 ○ ○ ○ ○ ○
09-05
COM2 Transmission
Speed (Keypad) 4.8~115.2Kbps 9.6 ○ ○ ○ ○ ○
09-06
COM2 Transmission
Fault Treatment
(Keypad) 0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning and keep operation 3 ○ ○ ○ ○ ○
09-07
COM2 Time-out
Detection (Keypad) 0.0~100.0 sec 0.0 ○ ○ ○ ○ ○
09-08
COM2 Communication
Protocol (Keypad) 0: 7N1 (ASCII)
1: 7N2 (ASCII)
2: 7E1 (ASCII)
3: 7O1 (ASCII)
4: 7E2 (ASCII)
5: 7O2 (ASCII)
6: 8N1 (ASCII)
7: 8N2 (ASCII)
8: 8E1 (ASCII)
9: 8O1 (ASCII)
10: 8E2 (ASCII)
11: 8O2 (ASCII)
12: 8N1 (RTU)
13: 8N2 (RTU)
14: 8E1 (RTU)
15: 8O1 (RTU)
16: 8E2 (RTU)
17: 8O2 (RTU) 13 ○ ○ ○ ○ ○
09-09 Response Delay Time 0.0~200.0ms
2.0 ○ ○ ○ ○ ○
09-10
Transmission Master
Frequency 0.00~600.00Hz 60.00 ○ ○ ○ ○
09-11
Block Transfer 1 0~65535 0 ○ ○ ○ ○ ○
09-12
Block Transfer 2 0~65535 0 ○ ○ ○ ○ ○
09-13
Block Transfer 3 0~65535 0 ○ ○ ○ ○ ○
09-14
Block Transfer 4 0~65535 0 ○ ○ ○ ○ ○
09-15
Block Transfer 5 0~65535 0 ○ ○ ○ ○ ○
09-16
Block Transfer 6 0~65535 0 ○ ○ ○ ○ ○
09-17
Block Transfer 7 0~65535 0 ○ ○ ○ ○ ○
09-18
Block Transfer 8 0~65535 0 ○ ○ ○ ○ ○
09-19
Block Transfer 9 0~65535 0 ○ ○ ○ ○ ○
