Chapter 4 Parameters|
4-60 Revision August 2008, 03VE, SW V2.04
02-04 Multi-Function Input Command 4 (MI4)
Factory Setting: 4
02-05 Multi-Function Input Command 5 (MI5)
Factory Setting: 0
02-06 Multi-Function Input Command 6 (MI6)
Factory Setting: 0
02-23 Multi-Function Input Command 7 (MI7)
Factory Setting: 0
02-24 Multi-Function Input Command 8 (MI8)
Factory Setting: 0
02-25 Multi-Function Input Command 9 (MI9)
Factory Setting: 0
02-26 Multi-Function Input Command 10 (MIA)
Factory Setting: 0
02-27 Multi-Function Input Command 11 (MIB)
Factory Setting: 0
02-28 Multi-Function Input Command 12
Factory Setting: 0
02-29 Multi-Function Input Command 13
Factory Setting: 0
02-30 Multi-Function Input Command 14
Factory Setting: 0
Settings 0-50
Control Mode
Settings
VF VFPG SVC FOCPG TQRPG
0: no function ○ ○ ○ ○ ○
1: multi-step speed command 1/multi-step position
command 1 ○ ○ ○ ○
2: multi-step speed command 2/ multi-step position
command 2 ○ ○ ○ ○
3: multi-step speed command 3/ multi-step position
command 3 ○ ○ ○ ○
4: multi-step speed command 4/ multi-step position
command 4 ○ ○ ○ ○
5: Reset ○ ○ ○ ○ ○
6: JOG command ○ ○ ○ ○
7: acceleration/deceleration speed inhibit ○ ○ ○ ○
8: the 1st, 2nd acceleration/deceleration time selection ○ ○ ○ ○
9: the 3rd, 4th acceleration/deceleration time selection ○ ○ ○ ○
10: EF input (07-36) ○ ○ ○ ○ ○
11: B.B. input ○ ○ ○ ○ ○
12: Output stop ○ ○ ○ ○ ○
