Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-79
Group 3 Analog Input/Output Parameters
03-00 Analog Input 1 (AVI)
Factory Setting: 1
03-01 Analog Input 2 (ACI)
Factory Setting: 0
03-02 Analog Input 3 (AUI)
Factory Setting: 0
Control Mode
Settings
VF VFPG SVC FOCPG TQRPG
0: No function ○ ○ ○ ○ ○
1: Frequency command (torque limit under TQR control
mode) ○ ○ ○ ○ ○
2: torque command (torque limit under speed mode) ○
3: Torque compensation command ○ ○ ○ ○ ○
4: PID target value (refer to group 8) ○ ○ ○ ○
5: PID feedback signal (refer to group 8) ○ ○ ○ ○
6: P.T.C. thermistor input value ○ ○ ○ ○ ○
7: Positive torque limit ○
8: Negative torque limit ○
9: Regenerative torque limit ○
10: Positive/negative torque limit ○
11: PID feedback signal of tension ○ ○ ○ ○ ○
12: Line speed ○ ○ ○ ○ ○
13: Reel diameter ○ ○ ○ ○ ○
14: PID target value of tension (tension closed-loop) ○ ○ ○ ○ ○
15: Tension setting (tension open-loop) ○
16: Zero-speed tension ○
17: Tension taper ○
When it is frequency command or TQR speed limit, the corresponding value for 0~±
10V/4~20mA is 0 – max. output frequency(Pr.01-00)
When it is torque command or torque limit, the corresponding value for 0~±10V/4~20mA is 0 –
max. output torque (Pr.07-22).
When it is torque compensation, the corresponding value for 0~±10V/4~20mA is 0 – rated
torque.
