Chapter 1 Introduction|
1-10 Revision August 2008, 03VE, SW V2.04
Frame B
H
W1
D
W
H1
D2
D1
S1
S2
Unit: mm[inch]
Frame W W1 H H1 D D1 D2 S1 S2
B1
150.0
[5.91] 135.0
[5.32] 260.0
[10.24]
244.3
[9.63] 160.2
[6.31] 67.0
[2.64]
4.0
[0.16]
8.0
[0.32]
6.5
[0.26]
B2
150.0
[5.91] 135.0
[5.32] 272.1
[10.72]
244.3
[9.63] 183.7
[7.24] 67.0
[2.64]
4.0
[0.16]
8.0
[0.32]
6.5
[0.26]
NOTE
Frame B1: VFD007V23A/43A-2, VFD015V23A/43A-2, VFD022V23A/43A-2
Frame B2: VFD037V23A/43A-2
