Appendix B Accessories|
Revision August 2008, 03VE, SW V2.04 B-29
B.9 AMD-EMI Filter Cross Reference
AC Drives Model Number FootPrint
VFD007V43A-2, VFD015V43A-2, VFD022V43A-2 RF022B43AA Y
VFD037V43A-2 RF037B43BA Y
VFD055V43A-2, VFD075V43A-2, VFD110V43A-2,
VFD110V43B-2
RF110B43CA Y
VFD007V23A-2, VFD015V23A-2 10TDT1W4C N
VFD022V23A-2, VFD037V23A-2 26TDT1W4C N
VFD055V23A-2, VFD075V23A-2, VFD150V43A-2,
VFD185V43A-2
50TDS4W4C N
VFD110V23A-2, VFD150V23A-2, VFD220V43A-2,
VFD300V43A-2, VFD370V43A-2
100TDS84C N
VFD550V43A-2, VFD750V43A-2, VFD550V43C-2,
VFD750V43C-2
200TDDS84C N
VFD185V23A-2, VFD220V23A-2, VFD300V23A-2,
VFD450V43A-2
150TDS84C N
VFD370V23A-2 180TDS84C N
Installation
All electrical equipment, including AC motor drives, will generate high-frequency/low-frequency noise
and will interfere with peripheral equipment by radiation or conduction when in operation. By using an
EMI filter with correct installation, much interference can be eliminated. It is recommended to use
DELTA EMI filter to have the best interference elimination performance.
We assure that it can comply with following rules when AC motor drive and EMI filter are installed
and wired according to user manual:
„ EN61000-6-4
„ EN61800-3: 1996 + A11: 2000
„ EN55011 (1991) Class A Group 1 (1 st Environment, restricted distribution)
General precaution
1. EMI filter and AC motor drive should be installed on the same metal plate.
2. Please install AC motor drive on footprint EMI filter or install EMI filter as close as possible to
the AC motor drive.
3. Please wire as short as possible.
4. Metal plate should be grounded.
