Chapter 4 Parameters|
4-72 Revision August 2008, 03VE, SW V2.04
Settings Functions Descriptions
21 Over-voltage Warning Active when the over-voltage is detected.
22
Over-current Stall
Prevention Warning
Active when the over-current stall prevention is detected.
23
Over-voltage Stall
prevention Warning
Active when the over-voltage stall prevention is detected.
24
Operation Mode
Indication Active when the operation command is controlled by external
terminal.
25 Forward Command Active when the operation direction is forward.
26 Reverse Command Active when the operation direction is reverse.
27
Output when Current >=
Pr.02-32
Active when current is >= Pr.02-32.
28
Output when Current <
Pr.02-32
Active when current is < Pr.02-32.
29
Output when frequency
>= Pr.02-33
Active when frequency is >= Pr.02-33.
30
Output when Frequency
< Pr.02-33
Active when frequency is < Pr.02-33.
31
Y-connection for the
Motor Coil Active when PR.05-12 is less than PR.05-11 and time is more
than Pr.05-30.
32
Δ-connection for the
Motor Coil Active when PR.05-12 is higher than PR.05-11 and time is
more than Pr.05-30.
33
Zero Speed (actual
output frequency) Active when the actual output frequency is 0. (the drive should
be at RUN mode)
34
Zero Speed with Stop
(actual output
frequency)
Active when the actual output frequency is 0 or Stop.
35
Error Output Selection 1
(Pr.06-23)
Active when Pr.06-23 is ON.
36
Error Output Selection 2
(Pr.06-24)
Active when Pr.06-24 is ON.
37
Error Output Selection 3
(Pr.06-25)
Active when Pr.06-25 is ON.
38
Error Output Selection 4
(Pr.06-26)
Active when Pr.06-26 is ON.
39
Position Attained
(Pr.10-19)
Active when the PG position control point reaches Pr.10-19.
