B.2 no-fuse circuit breaker chart – Delta Electronics AC Motor Drive VFD-VE Series User Manual
Page 248
Appendix B Accessories|
Revision August 2008, 03VE, SW V2.04
B-9
B.2 No-fuse Circuit Breaker Chart
For 3-phase drives, the current rating of the breaker shall be within 2-4 times maximum input current
rating.
(Refer to Appendix A for rated input current)
3-phase
Model
Recommended no-fuse
breaker (A)
Model
Recommended no-fuse
breaker (A)
VFD007V23A-2 10 VFD110V43B-2 50
VFD007V43A-2 5 VFD150V23A-2
125
VFD015V23A-2 15 VFD150V43A-2 60
VFD015V43A-2 10 VFD185V23A-2 150
VFD022V23A-2 30 VFD185V43A-2 75
VFD022V43A-2 15 VFD220V23A-2 175
VFD037V23A-2 40 VFD220V43A-2 100
VFD037V43A-2 20 VFD300V23A-2 225
VFD055V23A-2 50 VFD300V43A-2 125
VFD055V43A-2 30 VFD370V23A-2 250
VFD075V23A-2 60 VFD370V43A-2 150
VFD075V43A-2 40 VFD450V43A-2 175
VFD110V23A-2 100 VFD550V43C-2 250
VFD110V43A-2 50 VFD750V43C-2 300
