Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-101
Control Mode
Settings
VF VFPG SVC FOCPG TQRPG
0: No fault ○ ○ ○ ○ ○
1: Over-current during acceleration (ocA) ○ ○ ○ ○ ○
2: Over-current during deceleration (ocd) ○ ○ ○ ○ ○
3: Over-current during constant speed (ocn) ○ ○ ○ ○ ○
4: Ground fault (GFF) ○ ○ ○ ○ ○
5: IGBT short-circuit (occ) ○ ○ ○ ○ ○
6: Over-curent at stop (ocS) ○ ○ ○ ○ ○
7: Over-voltage during acceleration (ovA) ○ ○ ○ ○ ○
8: Over-voltage during deceleration (ovd) ○ ○ ○ ○ ○
9: Over-voltage during constant speed (ovn) ○ ○ ○ ○ ○
10: Over-voltage at stop (ovS) ○ ○ ○ ○ ○
11: Low-voltage during acceleration (LvA) ○ ○ ○ ○ ○
12: Low-voltage during deceleration (Lvd) ○ ○ ○ ○ ○
13: Low-voltage during constant speed (Lvn) ○ ○ ○ ○ ○
14: Low-voltage at stop (LvS) ○ ○ ○ ○ ○
15: Phase loss (PHL) ○ ○ ○ ○ ○
16: IGBT heat sink over-heat (oH1) ○ ○ ○ ○ ○
17: Heat sink over-heat (oH2)(for 40HP above) ○ ○ ○ ○ ○
18: TH1 open loop error (tH1o) ○ ○ ○ ○ ○
19: TH2 open loop error (tH2o) ○ ○ ○ ○ ○
20: Fan error signal output ○ ○ ○ ○ ○
21: over-load (oL) (150% 1Min) ○ ○ ○ ○ ○
22: Motor 1 over-load (EoL1) ○ ○ ○ ○ ○
23: Motor 2 over-load (EoL2) ○ ○ ○ ○ ○
24: Motor PTC overheat (oH3) ○ ○ ○ ○ ○
25: Fuse error (FuSE) ○ ○ ○ ○ ○
26: over-torque 1 (ot1) ○ ○ ○ ○ ○
27: over-torque 1 (ot2) ○ ○ ○ ○ ○
28: Reserved
29: Reserved
30: Memory write-in error (cF1) ○ ○ ○ ○ ○
31: Memory read-out error (cF2) ○ ○ ○ ○ ○
32: Isum current detection error (cd0) ○ ○ ○ ○ ○
33: U-phase current detection error (cd1) ○ ○ ○ ○ ○
34: V-phase current detection error (cd2) ○ ○ ○ ○ ○
35: W-phase current detection error (cd3) ○ ○ ○ ○ ○
36: Clamp current detection error (Hd0) ○ ○ ○ ○ ○
37: Over-current detection error (Hd1) ○ ○ ○ ○ ○
38: Over-voltage detection error (Hd2) ○ ○ ○ ○ ○
39: Ground current detection error (Hd3) ○ ○ ○ ○ ○
40: Auto tuning error (AuE) ○ ○ ○
41: PID feedback loss (AFE) ○ ○ ○ ○ ○
42: PG feedback error (PGF1) ○ ○ ○
43: PG feedback loss (PGF2) ○ ○ ○
44: PG feedback stall (PGF3) ○ ○
45: PG slip error (PGF4) ○ ○
46: PG ref input error (PGr1) ○ ○ ○ ○ ○
47: PG ref loss (PGr2) ○ ○ ○ ○ ○
48: Analog current input loss (ACE) ○ ○ ○ ○ ○
49: External fault input (EF) ○ ○ ○ ○ ○
50: Emergency stop (EF1) ○ ○ ○ ○ ○
51: External Base Block (B.B.) ○ ○ ○ ○ ○
