Chapter 4 Parameters|
4-88 Revision August 2008, 03VE, SW V2.04
05-01 Full-load Current of Motor 1
Control
mode
VF VFPG SVC FOCPG TQRPG
Factory setting: #.##
Settings 40 to 100%
This value should be set according to the rated frequency of the motor as indicated on the
motor nameplate. The factory setting is 90% X rated current.
Example: The rated current for 7.5HP (5.5kW) is 25 and factory setting is 22.5A. The range for
setting will be 10~30A.(25*40%=10 and 25*120%=30)
05-02 Rated Power of Motor 1 Unit: 0.01
Control
mode
SVC FOCPG TQRPG
Factory setting: #.##
Settings 0 to 655.35 kW
It is used to set rated power of the motor 1. The factory setting is the power of the drive.
05-03 Rated Speed of Motor 1 (rpm) Unit: 1
Control
mode
VFPG SVC FOCPG TQRPG
Factory setting: 1710 (60Hz, 4 poles)
1410 (50Hz, 4 poles)
Settings 0 to 65535
It is used to set the rated speed of the motor and need to set according to the value indicated
on the motor nameplate.
05-04 Number of Motor Poles 1
Control
mode
VF VFPG SVC FOCPG TQRPG
Factory setting: 4
Settings 2 to 20
It is used to set the number of motor poles (must be an even number).
05-05 No-load Current of Motor 1 Unit: Amp
Control
mode
VFPG SVC FOCPG TQRPG
Factory setting: #.##
Settings 0 to factory setting of Pr.05-01
The factory setting is 40% X rated current.
