Chapter 4 Parameters|

Revision August 2008, 03VE, SW V2.04

4-107

Group 7 Special Parameters

07-00

Software Brake Level

Unit: 0.1

Control

mode

VF VFPG SVC

FOCPG TQRPG

Settings 230V series 350.0~450.0Vdc

Factory Setting: 380.0

460V series 700.0~900.0Vdc

Factory Setting: 760.0

This parameter sets the DC-bus voltage at which the brake chopper is activated.

07-01

DC Brake Current Level

Unit: 1

Control

mode

VF VFPG SVC

FOCPG TQRPG

Factory Setting: 0

Settings

0 to 100%

This parameter sets the level of DC Brake Current output to the motor during start-up and

stopping. When setting DC Brake Current, the Rated Current (Pr.00-01) is regarded as 100%.

It is recommended to start with a low DC Brake Current Level and then increase until proper

holding torque has been attained.

When it is in FOCPG/TQRPG mode, it can enable DC brake function by setting to any value.

07-02

DC Brake Time during Start-up

Unit: 0.1

Control

mode

VF VFPG SVC

FOCPG TQRPG

Factory Setting: 0.0

Settings

0.0 to 60.0 sec

This parameter determines the duration of the DC Brake current after a RUN command. When

the time has elapsed, the AC motor drive will start accelerating from the Minimum Frequency

(Pr.01-05).

07-03

DC Brake Time during Stopping

Unit: 0.01

Control

mode

VF VFPG SVC

FOCPG TQRPG

Factory Setting: 0.00

Settings

0.00 to 60.00 sec

This parameter determines the duration of the DC Brake current during stopping.

07-04

Start-Point for DC Brake

Unit: 0.01

Control

mode

VF VFPG SVC

TQRPG

Factory Setting: 0.00

Settings

0.00 to 600.00Hz

This parameter determines the frequency when DC Brake will begin during deceleration.
