Chapter 4 Parameters|

4-70

Revision August 2008, 03VE, SW V2.04

Control Mode

Settings

VF

VFPG

SVC

FOCPG TQRPG

12: Mechanical brake release (Pr.02-31)

13: Overheat

14: Software brake signal

15: PID feedback error

16: Slip error (oSL)

17: Terminal count value attained (Pr.02-16)

18: Preliminary count value attained (Pr.02-17)

19: Baseblock (B.B.) Indication

20: Warning output

21: Over voltage warning

22: Over-current stall prevention warning

23: Over-voltage stall prevention warning

24: Operation mode indication

25: Forward command

26: Reverse command

27: Output when current >= Pr.02-32

28: Output when current < Pr.02-32

29: Output when frequency >= Pr.02-33

30: Output when frequency < Pr.02-33

31: Y-connection for the motor coil

32:

Δ

connection for the motor coil

33: Zero speed (actual output frequency)

34: Zero speed with Stop (actual output frequency)

35: Error output selection 1 (Pr.06-23)

36: Error output selection 2 (Pr.06-24)

37: Error output selection 3 (Pr.06-25)

38: Error output selection 4 (Pr.06-26)

39: Position attained (Pr.10-19)

40: Speed attained (including zero speed)

41: Multi-position attained

42: Crane function

43: Motor zero-speed output (Pr.02-43)

44: Max. reel diameter attained

45: Empty reel diameter attained

46: Broken belt detection

47: Break release at stop

48: Error PID feedback of tension

49:

Reserved

50:

Reserved

Settings

Functions

Descriptions

0 No

Function

1

Operation Indication

Active when the drive is not at STOP.

2

Master Frequency
Attained

Active when the AC motor drive reaches the output frequency
setting.

3

Desired Frequency
Attained 1 (Pr.02-19)

Active when the desired frequency (Pr.02-19) is attained.
