5-4
MAXQ610 User’s Guide
Table 5-3. Peripheral Register Reset Values (continued)
REG
BIT
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
EIF1 0 0 0 0 0 0 0 0
EIE1 0 0 0 0 0 0 0 0
PI0 s s s s s s s s
PI1 s s s s s s s s
PI2 s s s s s s s s
PI3 s s s s s s s s
EIES0 0 0 0 0 0 0 0 0
EIES1 0 0 0 0 0 0 0 0
PD0 s s s s s s s s
PD1 s s s s s s s s
PD2 s s s s s s s s
PD3 s s s s s s s s
CHPREV s s s s s s s s
PO4 0 0 0 0 0 0 0 0
WUTC 0 0 0 0 0 0 0 0
WUT 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PI4 0 0 s s s s s s
PWCN 0 0 0 0 0 0 s s s 1 1 0 0 0 0 0
PD4 0 0 s s s s s s
TB0R 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB0CN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB1R 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB1CN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IRCN 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IRCA 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IRMT 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IRCNB 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB0C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB0V 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB1C 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
TB1V 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IRV 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SCON0 0 0 0 0 0 0 0 0
SBUF0 0 0 0 0 0 0 0 0
SCON1 0 0 0 0 0 0 0 0
SBUF1 0 0 0 0 0 0 0 0
SPIB 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SPICN 0 0 0 0 0 0 0 0
PR0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SMD0 0 0 0 0 0 0 0 0
PR1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SMD1 0 0 0 0 0 0 0 0
SPICF 0 0 0 0 0 0 0 0
SPICK 0 0 0 0 0 0 0 0
