4-4
MAXQ610 User’s Guide
Table 4-3. System Register Bit Reset Values
Note 1: Bits marked as “s” are static across some or all resets.
Note 2: ULDR/UAPP reset values shown are for parts with 64KB/512B per page of program space. The reset value is the first
page address past the available program memory on all resets.
REG
BIT
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
AP 0 0 0 0 0 0 0 0
APC 0 0 0 0 0 0 0 0
PRIV 0 0 0 0 1 1 1 1
PRIVT0 0 0 0 0 0 0 0 0
PSF 1 0 0 0 0 0 0 0
IC 0 0 0 0 1 1 0 0
PRIVT1 0 0 0 0 0 0 0 0
SC 0 0 0 0 0 1 s s 1 0 0 0 0 0 s 0
IPR0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PRIVF 0 0 0 0 0 0 0 0
ULDR 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0
UAPP 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0
CKCN s s s 0 0 0 0 0
WDCN s s 0 0 0 s s 0
A[0:15] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
PFX[0:7] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
IP 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
SP 0 0 0 0 0 0 1 1 1 1 1 1 0 0 0 0
IV 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0
LC[0] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
LC[1] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
OFFS 0 0 0 0 0 0 0 0
DPC 0 0 0 0 0 0 0 0 0 1 0 1 1 1 0 0
GR 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GRL 0 0 0 0 0 0 0 0
BP 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GRS 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
GRH 0 0 0 0 0 0 0 0
GRXL 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FP 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DP[0] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
DP[1] 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
CP 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
