14-2
MAXQ610 User’s Guide
Table 14-1. MAXQ610 Instruction Set Summary (continued)
Note 1: The active accumulator (Acc) is not allowed as the src in operations where it is the implicit destination .
Note 2: The CPU stalls when code is executed from flash with the destination being an IP register or when the code pointer is
used . This stall requires two execution cycles to complete the instruction .
Note 3: Only module 8 and modules 0 to 5 (when implemented for a given product) are supported by these single-cycle bit opera-
tions . Potentially affects C or E if PSF register is the destination . Potentially affects S and/or Z if AP or APC is the destination .
Note 4: The ‘{L/S}’ prefix is optional .
Note 5: Instructions that attempt to simultaneously push/pop the stack (e .g ., PUSH @SP--, PUSH @SPI--, POP @++SP, POPI
@++SP) or modify SP in a conflicting manner (e .g ., MOVE SP, @SP--) are invalid .
Note 6: The enabled AP autoincrement or decrement operation occurs for operations when specifying the active accumulator
(Acc) as the source or destination (i .e ., MOVE Acc, src; MOVE dst, Acc; MOVE Acc, Acc) . Special cases: If ‘MOVE APC,
Acc’ sets the APC .CLR bit, AP is cleared, overriding any autoinc/dec/modulo operation specified for AP . If ‘MOVE AP,
Acc’ causes an autoinc/dec/modulo operation on AP, this overrides the specified data transfer (i .e ., Acc is not trans-
ferred to AP) .
Note 7: Exception for MOVE instruction, MOVE dp, @cp requires three cycles .
Note 8: The terms Acc and A[AP] can be used interchangeably to denote the active accumulator .
Note 9: Any index represented by or found inside [ ] brackets is considered variable, but required .
Note 10: The active accumulator (Acc) is not allowed as the dst if A[AP] is specified as the src .
MNEMONIC DESCRIPTION
16-BIT INSTRUCTION
WORD
STATUS
BITS
AFFECTED
AP
INC/DEC
EXECUTION
CYCLES
NOTES
BRANCHING
{L/S}JUMP src IP ← IP + src or src f000 1100 ssss ssss — — 2 4
{L/S}JUMP C, src If C=1, IP ← (IP + src) or src f010 1100 ssss ssss — — 2 4
{L/S}JUMP NC, src If C=0, IP ← (IP + src) or src f110 1100 ssss ssss — — 2 4
{L/S}JUMP Z, src If Z=1, IP ← (IP + src) or src f001 1100 ssss ssss — — 2 4
{L/S}JUMP NZ, src If Z=0, IP ← (IP + src) or src f101 1100 ssss ssss — — 2 4
{L/S}JUMP E, src If E=1, IP ← (IP + src) or src 0011 1100 ssss ssss — — 2 4
{L/S}JUMP NE, src If E=0, IP ← (IP + src) or src 0111 1100 ssss ssss — — 2 4
{L/S}JUMP S, src If S=1, IP ← (IP + src) or src f100 1100 ssss ssss — — 2 4
{L/S}DJNZ LC[n], src If --LC[n] <> 0, IP← (IP + src) or src f10n 1101 ssss ssss — — 2 4
{L/S}CALL src @++SP ← IP+1; IP ← (IP+src) or src f011 1101 ssss ssss — — 2 4, 5
RET IP ← @SP-- 1000 1100 0000 1101 — — 2 —
RET C If C=1, IP ← @SP-- 1010 1100 0000 1101 — — 2 —
RET NC If C=0, IP ← @SP-- 1110 1100 0000 1101 — — 2 —
RET Z If Z=1, IP ← @SP-- 1001 1100 0000 1101 — — 2 —
RET NZ If Z=0, IP ← @SP-- 1101 1100 0000 1101 — — 2 —
RET S If S=1, IP ← @SP-- 1100 1100 0000 1101 — — 2 —
RETI IP ← @SP-- ; IPS←11b 1000 1100 1000 1101 — — 2 —
RETI C If C=1, IP ← @SP-- ; IPS←11b 1010 1100 1000 1101 — — 2 —
RETI NC If C=0, IP ← @SP-- ; IPS←11b 1110 1100 1000 1101 — — 2 —
RETI Z If Z=1, IP ← @SP-- ; IPS←11b 1001 1100 1000 1101 — — 2 —
RETI NZ If Z=0, IP ← @SP-- ; IPS←11b 1101 1100 1000 1101 — — 2 —
RETI S If S=1, IP ← @SP-- ; IPS←11b 1100 1100 1000 1101 — — 2 —
D
A
T
A
T
R
A
N
S
F
E
R
XCH Swap Acc bytes 1000 1010 1000 1010 S Y 1 —
XCHN Swap nibbles in each Acc byte 1000 1010 0111 1010 S Y 1 —
MOVE dst, src dst ← src fddd dddd ssss ssss C, S, Z, E (Note 6) (Notes 2, 7) 5, 6
PUSH src @++SP ← src f000 1101 ssss ssss — — (Note 2) 5
POP dst dst ← @SP-- 1ddd dddd 0000 1101 C, S, Z, E — (Note 2) 5
POPI dst dst ← @SP-- ; IPS←11b 1ddd dddd 1000 1101 C, S, Z, E — (Note 2) 5
CMP src E ← (Acc = src) f111 1000 ssss ssss E — 1 —
NOP No operation 1101 1010 0011 1010 — — 1 —
