14-10
MAXQ610 User’s Guide
Table 14-2. Source Specifier Codes
src
src BIT
ENCODING
f ssssssss
WIDTH
16 OR 8
DESCRIPTION
#k 0 kkkk kkkk 8 kkkkkkkk = Immediate (Literal) Data
MN[n] 1 nnnn 0NNN 8/16
nnnn Selects One of 1st 16 Registers in Module NNN, shere NNN = 0 to 5;
Access to 2nd 16 Using PFX[n]
AP 1 0000 1000 8 Accumulator Pointer
APC 1 0001 1000 8 Accumulator Pointer Control
PSF 1 0100 1000 8 Processor Status Flag Register
IC 1 0101 1000 8 Interrupt and Control Register
SC 1 1000 1000 8 System Control Register
IPR0 1 1001 1000 8 Interrupt Priority Register Zero
CKCN 1 1110 1000 8 Clock Control Register
WDCN 1 1111 1000 8 Watchdog Control Register
A[n] 1 nnnn 1001 8/16 nnnn Selects One of 16 Accumulators
Acc 1 0000 1010 8/16 Active Accumulator = A[AP]; Update AP per APC
A[AP] 1 0001 1010 8/16 Active Accumulator = A[AP]; No Change to AP
IP 1 0000 1100 16 Instruction Pointer
@SP-- 1 0000 1101 16 16-Bit Word @SP, Pop (Postincrement SP)
SP 1 0001 1101 16 Stack Pointer
IV 1 0010 1101 16 Interrupt Vector
LC[n] 1 011n 1101 16 n Selects One of Two Loop Counter Registers
@SPI-- 1 1000 1101 16 16-Bit Word @SP, Pop (Postincrement SP), IPS = 11b
@BP[OFFS] 1 0000 1110 8/16 Data Memory @BP[OFFS]
@BP[OFFS++] 1 0001 1110 8/16 Data Memory @BP[OFFS]; Postincrement OFFS
@BP[OFFS--] 1 0010 1110 8/16 Data Memory @BP[OFFS]; Postdecrement OFFS
OFFS 1 0011 1110 8 Frame Pointer Offset from Base Pointer (BP)
DPC 1 0100 1110 16 Data Pointer Control Register
GR 1 0101 1110 16 General Register
GRL 1 0110 1110 8 Low Byte of GR Register
BP 1 0111 1110 16 Frame Pointer Base Pointer (BP)
GRS 1 1000 1110 16 Byte-Swapped GR Register
GRH 1 1001 1110 8 High Byte of GR Register
GRXL 1 1010 1110 16 Sign Extended Low Byte of GR Register
FP 1 1011 1110 16 Frame Pointer (BP[OFFS])
@DP[n] 1 0n00 1111 8/16 Data Memory @DP[n]
@DP[n]++ 1 0n01 1111 8/16 Data Memory @DP[n], Postincrement DP[n]
@DP[n]-- 1 0n10 1111 8/16 Data Memory @DP[n], Postdecrement DP[n]
DP[n] 1 0n11 1111 16 n Selects One of Two Data Pointers
@CP 1 1000 1111 8/16 Code Memory @CP
@CP++ 1 1001 1111 8/16 Code Memory @CP, Postincrement DP[n]
@CP-- 1 1010 1111 8/16 Code Memory @CP, Postdecrement DP[n]
CP 1 1011 1111 16 Code Pointer
