7-10
MAXQ610 User’s Guide
7.2.2 Timer B Value Register (TBV)
7.2.3 Timer B Capture/Reload Value Register (TBR)
7.2.4 Timer B Compare Register (TBC)
15 0
Timer B Value Register (TBV)
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
Power-On Reset and System Resets
Read (r), Write (w), or Special (s) access
The TBV register is a 16-bit register that holds the cur-
rent Timer B value .
15 0
Timer B Compare Register (TBC)
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
Power-On Reset and System Resets
Read (r), Write (w), or Special (s) access
This register is used to compare against TBV when
Timer B operates in compare mode .
15 0
Timer B Capture/Reload Value Register (TBR)
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
0
rw
Power-On Reset and System Resets
Read (r), Write (w), or Special (s) access
This 16-bit register is used to capture the TBV value
when Timer B is configured in capture mode and
holds the reload value when Timer B is configured in
autoreload mode .
