14-6
MAXQ610 User’s Guide
CMP src Compare Accumulator
Description: Compare for equality between the active accumulator and the least significant byte of the specified
src . The PFX[n] register may be used to supply the high byte of data for 8-bit sources .
Status Flags: E
Operation: Acc = src: E ← 1
Acc ≠ src: E ← 0
Encoding: 15 0
f111 1000 ssss ssss
Example(s): CMP #45h ; Acc = 0145h, E=0
CMP #145h ; PFX[0] register used
; MOVE PFX[0], #01h (smart-prefixing)
; CMP #45h E=1
CPL Complement Acc
Description: Performs a logical bitwise complement (one’s complement) on the active accumulator (Acc or
A[AP]) and returns the result to the active accumulator .
Status Flags: S, Z
Operation: Acc ← ~Acc
Encoding: 15 0
1000 1010 0001 1010
Example(s): ; Acc = 0FFFFh, S=1, Z=0
CPL ; Acc ← 0000h, S=0, Z=1
; Acc = 0990h, S=0, Z=0
CPL ; Acc ← F66Fh, S=1, Z=0
CPL C Complement Carry Flag
Description: Logically complements the Carry (C) Flag .
Status Flag: C
Operation: C ← ~C
Encoding: 15 0
1101 1010 0010 1010
Example(s): ; C = 0
CPL C ; C ← 1
{L/S}DJNZ LC[n], src Decrement Counter, {Long/Short} Jump Not Zero
Description: The DJNZ LC[n], src instruction performs a conditional branch based upon the associated Loop
Counter (LC[n]) register . The DJNZ LC[n], src instruction decrements the LC[n] loop counter
and branches to the address defined by src if the decremented counter has not reached 0000h .
Program branches can be relative or absolute depending upon the src specifier and may be quali-
fied by using the ‘L’ or ‘S’ prefixes as documented in the JUMP src opcode .
Status Flags: None
Operation: LC[n] ← LC[n] –1
LC[n] ≠ 0: IP ← IP + src (relative) –or— src (absolute)
LC[n] = 0: IP ← IP + 1
