10.8.3 SPI Clock Register (SPICK)
Bits 7:0: Clock Divider Ratio Bits 7:0 (CKR[7:0]). This 8-bit value determines the system clock divide ratio to be
used for SPI master mode baud-clock generation . This register has no function when operating in slave mode as the
SPI clock generation circuitry is disabled . The frequency of the SPI master-mode baud rate is calculated using the
following equation:
SPI Baud Rate = (0 .5 x System Clock Frequency)/(CKR[7:0] + 1)
10.8.4 SPI Data Buffer Register (SPIB)
Data for SPI is read from or written to this location . The serial transmit and receive buffers are separate, but both are
addressed at this location . Write access is allowed only outside the transfer cycle . When the STBY bit is set, write
attempts are blocked and cause a write collision error .
7
