3-18
MAXQ610 User’s Guide
move @++DP[1], @DP[1]--
move @BP[++Offs], @BP[Offs--]
move @--DP[0], @DP[0]++
move @--DP[1], @DP[1]++
move @BP[--Offs], @BP[Offs++]
move @DP[0], @DP[0]++
move @DP[1], @DP[1]++
move @BP[Offs], @BP[Offs++]
move @DP[0], @DP[0]--
move @DP[1], @DP[1]--
move @BP[Offs], @BP[Offs--]
move DP[0], @DP[0]++
move DP[0], @DP[0]--
move DP[1], @DP[1]++
move DP[1], @DP[1]--
move Offs, @BP[Offs--]
move Offs, @BP[Offs++]
3.10 Using the Watchdog Timer
The watchdog timer is a user-programmable clock counter that can serve as a time-base generator, an event timer,
or a system supervisor . As shown in Figure 3-1, the main system clock drives the timer, which is supplied to a series
of dividers . If the watchdog interrupt and the watchdog reset are disabled (EWDI = 0 and EWT = 0), the watchdog
timer and its input clock are disabled . Whenever the watchdog timer is disabled, the watchdog interval timer (through
the WD[1:0] bits) and the 512-clock reset counter are reset if either the interrupt or reset function is enabled . When
the watchdog timer is initially enabled, there is a one- to three-clock-cycle delay before it starts . The divider output is
selectable and determines the interval between timeouts . When the timeout is reached, an interrupt flag is set, and,
if enabled, an interrupt occurs . A watchdog-reset function is also provided in addition to the watchdog interrupt . The
reset and interrupt are completely discrete functions that can be acknowledged or ignored, together or separately, for
various applications .
The watchdog timer reset function works as follows: After initializing the correct timeout interval (discussed below),
software can enable, if desired, the reset function by setting the enable watchdog timer reset (EWT = WDCN .1) bit .
Setting the EWT bit resets/restarts the watchdog timer if the watchdog interrupt is not already enabled . At any time
prior to reaching its user-selected terminal value, software can set the reset watchdog timer (RWT = WDCN .0) bit . If
the watchdog timer is reset (RWT bit written to 1) before the timeout period expires, the timer starts over . Hardware
automatically clears RWT after software sets it .
Table 3-2. Watchdog Timer Register Control Bits
BIT NAME DESCRIPTION REGISTER LOCATION BIT POSITION
EWDI Enable Watchdog Timer Interrupt
WDCN (0Fh, 8h)
WDCN .6
WD[1:0] Watchdog Interval Control Bits WDCN[5:4]
WDIF Watchdog Interrupt Flag WDCN .3
WTRF Watchdog Timer Reset Flag WDCN .2
EWT Enable Watchdog Timer Reset WDCN .1
RWT Reset Watchdog Timer WDCN .0
