MAXQ610 User’s Guide
Figure 8-8. Sony Remote Encoding Example
1 1 0
1 1 0 0
0
0
0
1 1 1 1 1 0 0 0 0 0
0
IRRXSEL = 10b
IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_2T
IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_T IRMT_2T IRMT_2T
IRMT_2T
IR INTERRUPT
IR INTERRUPT
IRDATA
(IRTXPOL = 1)
IRTX
IRDATA
IRMT CAPTURE
IRRX
NOTE: 0 = 1T HIGH, 1T LOW, 1 = 2T HIGH, 1T LOW, VARIED BIT LENGTH.
0 0 0 0 1 1 1 1
