52

Standalone monitoring

Welch Allyn Propaq LT Vital Signs Monitor

Figure 55. Start-up with saved data

Monitoring ECG and Resp

Overview

You can monitor heart signs (ECG) and respiration rate (Resp) using either a 3-lead or a
5-lead ECG cable. Using a 3-lead cable, you can display one signal waveform for Lead I, II,
or III. Using a 5-lead cable, you can display either one or two signal waveforms (I, II, III, V;
and if enabled in the configuration, aV

R

, aV

L

, or aV

F

). You can also display the SpO

2

or

Resp waveform in place of an ECG waveform.

Select ( ) to continue

Select ( ) to continue
monitoring this patient.

monitoring this patient.

Portland Westside Hospital

Portland Westside Hospital

Emergency Department

Emergency Department

Note!

Note!

There is patient data stored for

There is patient data stored for

Hall, Robert E. ID: 3456187

Hall, Robert E. ID: 3456187

Start New Patient

Start New Patient

Continue Patient

Continue Patient

Info

Info Demo

Demo

Note

In this manual, lead refers to an ECG electrode or lead wire, and Lead refers to a
waveform source.

WARNING Always monitor and set alarms for SpO

2

when using impedance

pneumography to monitor respiratory function.

WARNING When monitoring respiration via impedance pneumography, always
select the ECG Lead with the most prominent QRS complex. The monitor rejects
cardiovascular artifact, but this function depends upon accurate ECG R-wave
detection.

WARNING Do not place the monitor near another respiration monitor. Resp
measurement frequencies can cause mutual interference.

WARNING Do not perform impedance pneumography on paced patients.
Pacemaker pulses can sometimes be falsely counted as breaths.

WARNING Always keep patient motion to a minimum. Motion artifact can cause
incorrect readings of breath rate or heart rate.

WARNING If a disconnected lead is too close to other electrical devices, it can
cause a false heart rate, a false respiration rate, or a failure to display a “Lead Fail”
message.

WARNING The monitor displays + + + for HR numerics between 301-350 beats
per minute. For heart rates above 350 beats per minute, it might display
incorrectly low heart readings, due to intermittent picking of R-waves.

WARNING The monitor does not provide internal arrhythmia analysis; therefore,
arrhythmias can cause the monitor to display inaccurate heart rates.

WARNING Make sure the patient mode is correct. Incorrect patient mode can
result in inaccurate heart rate readings and inappropriate alarm settings.
