108 Monitor configuration Welch Allyn Propaq LT Vital Signs Monitor
Display 2
Format Single waveform Large Numerics, Single Waveform,
Dual Waveform, Tabular Trends,
Tabular Trends with Waveform Monitor, Configuration
Utility
Top Waveform (if any) Lead II Lead I, Lead II, Lead III, Lead V, aVR, aVL,
aVF, SpO
2
, Resp
Monitor, Configuration
Utility
Show Top Waveform 6
Seconds No Yes, No Monitor, Configuration
Utility
Show Bottom Waveform 6
Seconds No Yes, No Monitor
Bottom Waveform (if any) Lead V Lead I, Lead II, Lead III, Lead V, aVR, aVL,
aVF, SpO
2
, Resp
Monitor, Configuration
Utility
Tabular Trends Display
Interval 5 min 1 min, 5 min, 10 min, 15 min, 30 min,
60 min Monitor, Configuration
Utility
Display 3
Format Tabular trends with
waveform Large Numerics, Single Waveform,
Dual Waveform, Tabular Trends,
Tabular Trends with Waveform Monitor, Configuration
Utility
Top Waveform (if any) Lead II Lead I, Lead II, Lead III, Lead V, aVR, aVL,
aVF, SpO
2
, Resp
Monitor, Configuration
Utility
Show Top Waveform 6
Seconds No Yes, No Monitor, Configuration
Utility
Show Bottom Waveform 6
Seconds No Yes, No Monitor
Bottom Waveform (if any) SpO
2
Lead I, Lead II, Lead III, Lead V, aVR, aVL,
aVF, SpO
2
, Resp
Monitor, Configuration
Utility
Tabular Trends Display
Interval 5 min 1 min, 5 min, 10 min, 15 min, 30 min,
60 min Monitor, Configuration
Utility
ECG
ECG Bandwidth Monitor Monitor, Extended Monitor, Configuration
Utility, Acuity
HR/PR general If the monitor language is French, please see the note under “Selecting a
language” on page 14.
HR/PR Selected Source ECG ECG, SpO
2
Monitor, Acuity
Can Disable HR/PR Alarm
Limits Yes
(No if lang=French) Yes, No Monitor
Power Source Filter 60 Hz 50 Hz, 60 Hz, Off Monitor, Configuration
Utility, Acuity
ParamSet for Upper HR/PR
Limit 20% 5% - 25% Configuration Utility
ParamSet for Lower HR/PR
Limit 20% 5% - 25% Configuration Utility
Table 10. Parameter configuration matrix (continued)
Parameter Factory setting Possible values Where set
