Directions for Use

Overview of monitor operation

23

Figure 16. Interface box mounted on the cradle

Figure 17. Interface box and cradle mounted on the large screen

Interface box mounted
on the cradle

Power conditioner

Interface box and cradle
mounted on the large screen

Power conditioner
