158 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Vibration, random 0.02g 2 /Hz from 10 to 500 Hz, ramping down to 0.002g 2 /Hz at 2000 Hz.
Superimposed sine frequencies of 30 Hz at 2.5 g and 60, 90, and 120 Hz at 1.5 g.
Operating 1 hour per axis, 3 hours per test.
Electromagnetic compatibility (EMC) with USB option EN60601 - 1 - 2:2001 Class A
without USB option EN60601 - 1 - 2:2001 Class B
Physical
Depth 6.0 in (15.24 cm)
Width 7.6 in (19.3 cm)
Height 5.7 in (14.48 cm) including feet
Weight 24 oz (0.68 kg)
Electrical
Rated input 12V to 28V DC, 22 W max, current is inversely proportional to input voltage.
Rated fuse (externally accessible) 3A, 250V, 2AG size, type T3A.
Rated output to cradle connector Monitor power = 2 Adc max @ 8.2V - 8.6V, depending on the battery charge level.
(See Charge Scheme, below.)
Charge scheme Constant current
 900 mA.
Constant current for preconditioning
 180 mA for pack voltage of 4.3V - 6.2V.
Constant voltage = 8.4V ± 0.06V total at the battery cells.
Charge termination triggers Charge current
 90 mA.
Total charge timeout
 4 hours.
Precondition charge timeout
 1 hour.
Charge time (with monitor on or off)
3 hours typical for battery fully discharged but not exhausted.
The cradle can precondition most exhausted batteries, which adds to the total
charge time.
Charging terminates when the battery is fully charged or when a fault is
detected.
Charge time required on a dead
battery before NIBP can be used. NIBP can be used as soon as monitor is powered by the cradle.
Output overcurrent Electronic overload protection. If overload occurs, monitor must be removed and
reinserted to reset the charger.
Cradle - to - monitor connector Hypertronics L - Series Module D,17 - pin male
Power input connector Hypertronics Panel Mount D02 size latching 3 - pin female
Status Indicators
Status light yellow Battery or cradle fault (time out, temperature out of range, a cell is overcharged,
overload, no battery or nonrejuvenatable battery in monitor.)
Status light green Monitor connected and battery charging
Status light off Monitor not connected, or monitor connected and battery fully charged
Power light green DC input power is being applied to the cradle.
Both lights off Cradle not powered, cradle fuse is blown, or cradle has shut itself down.
Communications Functions
Cradle to attached PC
communications Per USB 1.1 (not fully compliant)
USB device type Vendor - defined class, Full - Speed Communications (12 MBPS)
USB ID Vendor: 0x0770
Device: 0x0802
USB connector USB type B female (device)
