28

Overview of monitor operation

Welch Allyn Propaq LT Vital Signs Monitor

Assembling the large color display

Refer to

Figure 24

,

Figure 25

on page 29, or

Figure 26

on page 30.

Figure 24. Mounting the interface box (with face plate) on the large display mounting bracket

60-mm screws
620-0431-00

40-mm screws
620-0432-00

Long cables between box and
cradle:
008-0946-00 (USB)
008-0948-00 (Power)

Power conditioner
