Directions for Use

Specifications

147

SpO

2

All sensors have a measurement range of 70% - 100%. SpO

2

complies with

EN ISO 9919:2005.

Characteristic

Specification

Saturation (% SpO

2

)

Range
Resolution

1% to 100%, but limited by sensors and by sensor manufacturers’ technology
1%

Alarm limits

50% to 98% (lower)
52% to 100% (upper)

Probe accuracy (adult, pediatric,
neonate)

Accuracy for saturation levels below 70% is unspecified.

Pulse rate alarm limits

25 to 298 beats/min (lower)
27 to 300 beats/min (upper)

Pulse rate accuracy

± 3 beats/min typical; varies with sensor model

Display update interval at the monitor

1 second

Alarm hold

-

off period

10 seconds; resets if the sensor reports levels within limits before 10 seconds
elapses.

Circuitry

Microprocessor controlled
Automatic self

-

test of oximeter when powered on

Automatic setting of default parameters
Automatic alarm messages

Electrosurgery interference suppression Yes

Sensor compatibility

For a complete list of compatible sensors, refer to the accessory list or

www.welchallyn.com

.

Nellcor

For probe/sensor compliance to EN ISO 9919:2005, see the Nellcor directions
for use.

Masimo

For probe/sensor compliance to EN ISO 9919:2005, see the Masimo directions
for use.

Sensor lights (Nellcor)

Red wavelength
Infrared wavelength

660 nm (nominal), 31.3 mW (max)
920 nm (nominal), 28.8 mW (max)

Sensor lights (Masimo)

Red wavelength
Red wavelength (toe clip)
Infrared wavelength
Infrared wavelength (toe clip)

15 mW at 50 mA pulsed

660 nm
663 nm
905 nm
880 nm

Risk mitigation: Software in this device is developed under the FDA guidance of Part 802.3 design controls and the
international standard EN 14971 risk management. These mitigate and minimize any risk associated with potential
software errors to a level as low as reasonably possible (ALARP).
