Overview of monitor operation

Welch Allyn Propaq LT Vital Signs Monitor

About monitor information screens

Both the start-up information screen and the monitoring information screen provide
information about the monitor.

To view the start-up information screen

From the power-on screen (

Figure 7

on page 13), highlight Info.

Figure 32. Start-Up Information

The start-up information screen provides the following:

Monitor type (LTRN=wireless, LT0N=standalone), serial #, and software version #
(V X.XX.XX)

Medical facility name and department

Configuration file name

Contact person’s name and telephone number

Current patient mode (Adult, Pediatric, Neonate)

Number of data snapshots saved (0 - 20)

Network communications status (Enabled, Disabled)

To exit the start-up information screen, do one of the following:

Highlight Continue Patient or Start New Patient to start monitoring.

Highlight Demo to enter Demo mode.

Press

to turn off the monitor.

Welch Allyn Propaq 802LTRN

Welch Allyn Propaq 802LTRN

Serial# F82C0DD5 V1.00.00

Serial# F82C0DD5 V1.00.00

Portland Westside

Portland Westside
Emergency Department

Emergency Department
PtldWstsdED10Jun05.mnt

PtldWstsdED10Jun05.mnt
Ann Jones, MD

Ann Jones, MD
503-530-0101 x9999

503-530-0101 x9999

Patient Mode

Patient Mode
Wireless Communications

Wireless Communications

Start New Patient

Start New Patient

Info

Info

Demo

Demo

Adult

Adult

Snapshots

Snapshots

none saved

none saved

Enabled

Enabled

Welch Allyn Propaq 802LT0N

Welch Allyn Propaq 802LT0N

Serial# AB72383-1 V1.00.00

Serial# AB72383-1 V1.00.00

Portland Westside

Portland Westside
Emergency Department

Emergency Department
PtldWstsdED10Jun05.mnt

PtldWstsdED10Jun05.mnt
Ann Jones, MD

Ann Jones, MD
503-530-0101 x9999

503-530-0101 x9999

Patient Mode

Patient Mode
Wireless Communications

Wireless Communications

Start New Patient

Start New Patient

Info

Info Demo

Demo

Adult

Adult

Snapshots

Snapshots

14 of 20 saved

14 of 20 saved

Disabled

Disabled

Continue Patient

Continue Patient
