Directions for Use

Overview of monitor operation

31

About navigation

You navigate the monitor screens using

,

,

and

(arrow buttons),

(action button),

and

(display button).

Using the arrow buttons

Use

,

,

and

to do the following:

Highlight an item on the display. (See

“Using the highlights”

on page 31.)

Select options from a control menu.

Use

and

to select options from a pop-up menu.

Use

and

to change the values of numeric parameters.

Using the action button

Use

to do the following:

Display the control menu for a blue-highlighted item.

Return from a control menu to the primary display.

Access the Setup menu when Setup is highlighted.

Display tabular and graphical trends when Trends is highlighted.

Display snapshots when Snapshot is highlighted.

Turn on the display or the back light if either has been turned off by a time-out.

Display a pop-up menu.

Using the display button

Use

to do the following:

Cycle through the configured display formats.

Return from a control menu to the primary display.

Close a pop-up menu.

Using the highlights

Every screen contains a single element—the current context—highlighted by a blue field.
Some screens also contain elements—parameter values—highlighted by a green field.

About blue highlights

A blue highlight identifies the current context. For example,

Figure 27

illustrates a

highlighted row in a trends display and a highlighted setting in the Waveform Size menu.
