156 Specifications Welch Allyn Propaq LT Vital Signs Monitor
Power
Power adapter
Characteristic Specifications
Operating times on a new fully-charged battery for ambient temperature 20 º C
Standalone
Continuous monitoring with minimal display use
(defined as 5 minutes display use per hour)
ECG and Resp only:
24 hrs
ECG, Resp, SpO
2
. NIBP every 15 min.:
8 hours
Acuity connected (Models 802LTAN, 802LTAS, 802LTRN
and 802LTRS)
In communication, with continuous monitoring and
minimal display use (5 min display use/hour) ECG and Resp only:
24 hrs
ECG, Resp, SpO
2
. NIBP every 15 min.:
8 hours
Characteristic Specification
Input 100-240 volts AC, 50/60 Hz, 700 mA max
Output 15 volts DC ± 5% no load to 2A load
Output ripple 200 mV p-p maximum (90 VAC RMS, 50 Hz, 24-watt load)
Power 24 watts minimum
Holdup time 1/2 sine-wave cycle, full load, 115 V/60 Hz, 230 VAC/50 Hz, per IEC EN 61000-4-11
Overvoltage protection Built in
Overcurrent protection Built in
Efficiency 80% minimum at full load, 115 VAC input
Dielectric withstanding
voltage 4.8 KV for 1 sec or 4.0 KV for 60 sec (mains) input to DC output
Patient leakage current 10
A maximum, normal condition type CF per IEC EN 60601-1
50
A maximum, single-fault condition type CF per IEC EN 60601-1
Enclosure leakage current 100
A maximum, per IEC EN 60601-1
Protection against harmful
ingress of water IPX1 when the LED faces up
IPX0 otherwise
Humidity 95% per MILT-28800 Par 4.5.5.1
Strain-Relief Strength 30 N per UL/IEC EN 60950-1 and UL/IEC EN 60601
Weight
 0.8 lb
Insulation class (transformer) UL Rated 105° C
Width 2.68 in (68 mm)
Height 1.54 in (39 mm)
Length 4.13 in (105 mm)
Weight 10.6 oz (300 g)
AC input connector IEC 60320 - C8, 2.5 A rated input housing
DC output connector Hypertronics DO2 - size latching 3 - pin male
Output cable length 8 feet for IEC power cord
