144

Specifications

Welch Allyn Propaq LT Vital Signs Monitor

Lead

-

fail sense current

70 nA DC typical for active leads
140

-

280 nA DC typical for reference electrode, depending on number attached.

Tall T

-

wave rejection

Meets AAMI (USA) EC13

-

2002, section 4.1.2.1.c, up through 1.2 mV, using AAMI test

waveform

Common mode rejection

FILTER function OFF
FILTER function ON

< 1 mV p

-

p RTI for 10V rms, 50/60 Hz into unbalanced input

< 30

V p

-

p RTI for 10V rms, 50/60 Hz into unbalanced input

Input impedance

> 2.5 M

 single

-

ended @ 60 Hz

Input range (AC)

10 mV peak

-

to

-

peak (local display)

10 mV peak

-

to

-

peak (Acuity)

Input range (DC)

Up to ±500 mV

Accuracy of input signal
reproduction -
Impulse response

Requires ECG bandwidth to be set to extended mode.
ANSI/AAMI:EC 13:2002, Sec 4.2.8.9.c

System noise

30 µV peak

-

to

-

peak, RTI notch filter on

Baseline recovery (trace
restore)

Automatic

QRS detector

Adult or pediatric amplitude range: 0.22 to 5.0 mV (RTI)
Neonate amplitude range: 0.1 to 5.0 mV
Adult width range (duration): 70 to 120 msec
Pediatric or neonate width range (duration): 40 to 120 msec

HR range (in all patient modes) 25 to 350 beats/min (measurement)

25 to 300 beats/min (display)

Alarm limits

25 to 298 beats/min (lower)
27 to 300 beats/min (upper)

HR resolution

1 beat/min

HR alarm resolution

5 beats/min

HR meter response time

Responds to change in heart rate within 13 seconds depending on physiological
waveform. (As measured per AAMI standard EC13

-

2002 clause 5.1.2.1 (f), including

4.1.2.1 parts f. and g. waveforms.) Includes 1

-

second readout update interval.

HR accuracy

±3 beats/min or 3%, whichever is greater

HR display update interval at
monitor

1 second

AAMI HR response to
“ineffectively paced QRS
pattern”

Indicates rate of 30 to 46 during AAMI EC13

-

2002 part 5.1.4 part (f), (g), and (h) tests.

NOTE: AAMI Test 5.1.4 part (f), (g), and (h): Accuracy is affected when QRS and pacer
spikes are nearly simultaneous as occasionally is the case during this test.

HR averaging method

HR = 60/(latest average interval in seconds)
For higher HR, latest avg interval = 7/8 (previous avg interval) + 1/8 (latest interval).
For lower HR, latest avg interval = 3/4 (previous avg interval) + 1/4 (latest interval).
Transition rates for choice of formula include hysteresis and are 70 and 80 beats/min.

Drift tolerance (AAMI spec.
EC13

-

2002, 4.2.6.3)

80 beats/min indicated for 80 beats/min ECG plus drift waveform

Pacer pulse display indication

Pacer indicator (dashed vertical marker) shown on screen if pacer indicator is ON; pacer
signal always shown if of sufficient amplitude.

Pacer pulse detection (i.e., for
which the monitor displays a
dashed vertical marker in
trace)

Pulses = ± 3.2 mV to ± 700 mV @ 0.1 ms and ± 2 mV to ± 700 mV @ 0.2 to 2 ms, all with
or without overshoot, in electrically quiet environment. Thresholds automatically adjust
to reject repetitive ambient noise. Pacer detector influences QRS picking even while
pacer display indication is disabled.
