Overview of monitor operation

Welch Allyn Propaq LT Vital Signs Monitor

Figure 26. Mounting the interface box and the cradle on the large display mounting bracket

40-mm screws
620-0432-00

60-mm screws
620-0431-00

Short cables between box
and cradle:
008-0947-00 (USB)
008-0949-00 (AC Power)

Power conditioner
