Application Examples • Thermoformer Application
383
Publication 1398-PM601A-EN-P — October 2000
APPENDIXES
ASSIGN SPEED
G3
;Move speed
ASSIGN ALPHA
G4
;Acceleration
ASSIGN TIME
G5
;Dwell time
ASSIGN OUT_LEN
G8
;Anticipation output length
ASSIGN REL_LEN
V31
;Output length relative to start of move
ASSIGN SCREEN
V34
;Current operator terminal screen
ASSIGN STATE
V35
;State of the control
ASSIGN TEMP_CNT
V38
;Temporary counter used for batch count
ASSIGN READY
I10
;I10 is the Ready input
ASSIGN ANTICIPATE
O2
;O2 is the Anticipate output
ASSIGN CUT
O3
;O3 is the Cut output
ASSIGN BATCH_CMPLT O4
;O4 is the Batch complete output
;
;Scanned event S1 turns the anticipate output on when
the position
;command exceeds the relative output length
S1:IF @PCMD > REL_LEN ANTICIPATE=ON
;
;This X1 key routine is used for operator entry of
; two different parameters for the thermoformer
; operation. The actual print and read statements
; used are determined by the variable SCREEN, which
; indicates which menu the operator interface is
; displaying.
X1:
;X1 key program
CLEAR 1
;Clear the operator terminal screen line 1
;Determine which menu is currently displayed
ON SCREEN JMP X1_0,X1_1,X1E
X1_0:
;If screen = 0 read new length
READ 1,4 "^D0LENGTH^D1 " ,SHOW LENGTH,7,3(0,999)
PRINT 1,1 "X1:LENGTH " ,LENGTH,7,3
JMP X1E
X1_1:
;If screen = 1 read new accel
READ 1,4 "^D0ACCEL^D1 " ,SHOW ALPHA,4,0(0,9999)
PRINT 1,1 "X1:ACCEL " ,ALPHA,4,0
ACCEL=ALPHA
;Update accel used for move
X1E:
XEND
;End of X1 key program
;
;The X2 key routine is similar to X1 for different
; variables.
X2:
;X2 key program
CLEAR 2
;Clear operator terminal line 2
;Determine which menu is currently displayed
ON SCREEN JMP X2_0,X2_1,X2E
X2_0:
;If screen = 0 read new speed
READ 2,4 "^D0SPEED^D1 " ,SHOW SPEED,4,0(0,9999)
PRINT 2,1 "X2:SPEED " ,SPEED,4,0
JMP X2E
X2_1:
;If screen = 1 read new dwell
READ 2,4 "^D0DWELL^D1 " ,SHOW TIME,6,3(0,99)
PRINT 2,1 "X2:DWELL " ,TIME,6,3
X2E:
XEND
;End of X2 key program
;
;The X3 key routine is similar to X1 for different
; variables.
X3:
;X3 key program
CLEAR 3
;Clear operator terminal line 3
;Determine which menu is currently displayed
ON SCREEN JMP X3_0,X3_1,X3E
X3_0:
;If screen = 0 read new count
