DELAY
Time Delay
Motion
Purpose
Delay for the specified time. Time is entered in seconds.
Syntax
DELAY = time
time
The time is specified in seconds and has a maximum value of
65,535 seconds. The time can be a constant, a nonvolatile vari-
able Gn, a volatile variable Vn, or a system variable. The reso-
lution of time is equal to the position loop update time (2mS).
Remarks
The compiler does not perform range checking for the maximum time for a DELAY
statement because the value may not be known until run time (value may be a vari-
able). However, if a program is run with a DELAY greater than 65, 535 seconds, the
ULTRA Plus or IQ will be disabled and flag the error as “Delay out of Range”.
Delay times are NOT affected by the feedrate. To define a delay that IS affected by the
feedrate, use the DWELL statement.
The DELAY statement can only be used in a subroutine or the main body of the pro-
gram. It may not be used in Fkey, Xkey, or Scanned Event routines.
See Also
DWELL, WAIT
Example
DELAY = 1.5
DELAY = G1
DH
Define Home
Home
Purpose
Define the present commanded position as the zero position. The current commanded
position will become 0, the encoder that is not the feedback encoder is set to a position
of zero, the Home Sequence Complete output (if assigned) and the HSEQCPL system
flag will be turned ON.
Syntax
DH
Remarks
Use caution if you use this command while there is motion. The time delay caused by
execution speed will result in the zero position being defined at a position that is dif-
ferent than when the command was issued. The difference in position will be propor-
tional to the velocity of the motor when the command was issued
This instruction is not permitted in a function key program (see DHCMD).
Any following error that is present when this instruction is executed will be main-
tained (the feedback position will not be set equal to the commanded position).
The Home Sequence Complete output is assigned in the Parameter menu, Outputs dia-
log box.
MOVP instructions are not permitted until the HSEQCPL system flag has been turned
ON.
See Also
DHCMD, DP (Define Position), DPn.
Example
DH
;Define the present position as the 0, home position
