374 Application Examples • Continuous Web with Registration
Publication 1398-PM601A-EN-P — October 2000
APPENDIXES
XEND
X2: ;X2 key routine
CLEAR
READ 3,1 "Gear Ratio: ",SHOW Ratio
GEAR=Ratio
CLEAR
XEND
X3: ;X3 key routine
CLEAR
PDelaybuf=PDelay*1000
IF TBASE=30000 PDelaybuf=PDelaybuf*60
PRINT 3,1 "Detector delay "
READ 4,1 "(mS): ",SHOW PDelaybuf
PDelaybuf = PDelaybuf/1000
IF TBASE=30000 PDelaybuf=PDelaybuf/60
PDelay=PDelaybuf
CLEAR
XEND
X4: ;X4 key routine
CLEAR
READ 3,1 "Window Radius: ",SHOW WindRad
IF (WindRad > Incr/2) WindRad=Incr/2
EnPos = Target - WindRad
DisPos = Target + WindRad
CLEAR
XEND
; ----------------------------- Start of Main Program ----------------------
main:
X1 CONT
X2 CONT
X3 CONT
X4 CONT
SCALE = 1 ;scales should already be set to 1
SCALE2 = 1
Incr = 8000 ;this value should be set to the correct value or
this
; line deleted and the assignment moved to an Xkey
Count = 0
DP -2147400000 ;start at close to the (-) Count limit
IF Offset >= 1 Offset = .5 ;if offset is valid, use it
IF Offset < 0 Offset = .5 ; otherwise use .5
Target =(Offset*Incr) - 2147400000
IF (WindRad > Incr/2) WindRad=Incr/2
EnPos = Target - WindRad
DisPos = Target + WindRad
OfsError = 0
S3 CONT
S4 CONT
InWin = OFF
IF Navg=0 Navg=1
Navgbuf=Navg ;make buffer current
CLEAR
GEAR = Ratio
GEAREN=ON
INT1 ON ;for the first time, scanned events
; do this from now on
Ck1: IF I15=OFF JMP Ck2;if I15=ON, offset forward
